Low Level Design: Logging Service

Every application, whether it is a banking system, an e-commerce platform, or a social media service, needs a reliable way to record what is happening internally while it is running. These records, called logs, help developers and operations teams understand application behavior, diagnose failures, trace important business events, and monitor the health of the system without directly inspecting the running code.

Scattering System.out.println() statements throughout the code quickly becomes difficult to manage. Different teams may produce logs in different formats, important information may be missing, and changing the output destination later would require modifying application code in multiple places.

The application developer should not need to worry about how a message is formatted, where it is stored, or whether multiple destinations are configured. By introducing a logging abstraction, the application can have a consistent logging format, configurable log levels, a reusable API, and the flexibility to route the same log message to multiple destinations without changing the business logic.

Functional Requirements

Design a logger library that:

1. Each log record should display timestamp, level, message, and emitting thread name.

2. Support different log levels (INFO, DEBUG, WARN, or ERROR) and allow the application to configure the minimum severity level that should be recorded.

3. Support multiple output destinations simultaneously. For example, an ERROR log could be written to both a file and a database.

4. The logging destinations should be extensible so that a new destination can be added without modifying the core logging logic.

5. Logging should have minimal impact on the application's performance. Where appropriate, log messages should be processed asynchronously rather than blocking the application thread.

6. A failure in one logging destination should not bring down the application or prevent the same log message from being delivered to other configured destinations.

Sequence Flow

A logging service acts as an abstraction between the application and the actual destination where logs are stored/printed.

1. Whenever an application wants to log an event, it calls the logger with a message and an appropriate severity level.

2. The logger creates a log record containing information such as timestamp, severity level, message, and emitting thread name.

3. The log record is then passed to the logging pipeline, where it is first checked against the configured log level. For example, if the application is configured to log only INFO and above, DEBUG messages will be discarded immediately. Valid logs are then passed to the configured destinations (commomly called appenders) such as console, file, database, or remote logging system.

Object-Model Design

(continue second iteration from here...)

In a production system, this processing is often performed asynchronously. Instead of making the application wait while a log is written to a file or sent over the network, the logger places the record into an in-memory queue. A background worker consumes records from the queue, formats or serializes them as required, and sends them to the configured destinations.

Q. Different processes in an application print logs simultaneously. How to handle this?

Multiple threads can call the logger.log(message) method simultaneously. The logger

Q. Does each destination decide its own filter level, or is there one global level on the logger?

Per destination. Each destination has its own minimum level. The console might want everything from DEBUG up, and the file destination might only care about WARN and above. Records below a destination's threshold should be dropped before being written.

Q. What goes there when sink.write() throws?

Naive Approach:

Don't catch anything. If sink.write() throws, the exception bubbles through Destination. write() and into Logger.log()'s iteration loop. The loop terminates and the exception keeps going up into the application code that called logger.error(...). However, The cost is severe in a multi-destination setup. Imagine you've configured a console sink, a file sink, and a future remote sink. The disk fills up. FileSink.write throws IOException. Logger.log() is mid-iteration when the exception fires, so the console got the record, but the remote never sees it. Worse, the exception now propagates into the application code that called logger.error("payment failed"). A logger is infrastructure that should never crash the caller. If a payment-processing function throws because logging failed, you've just turned a logging problem into a payment problem. Anyone reading the resulting stack trace will spend an hour chasing a payment bug that doesn't exist.

Better Approach:

Catch any exception from sink.write() and discard it. The destination's failure is its own problem. Other destinations and the calling code never see it.

write(record):
    if record.level < minLevel: return
    formatted = formatter.format(record)
    lock.acquire()
    try:
        sink.write(formatted)
    catch e:
        // swallow; don't crash the logger
    finally:
        lock.release()

The downside is silent failure. If your file destination is broken, you get no signal at all. The application keeps running. The console keeps showing logs. But the file you depend on for forensic analysis has been empty for three days, and you won't notice until something else goes wrong and you go looking. For a production logger this is a real operational problem - the logger is failing exactly when you most need it to be working.

Suitable Approach:

Catch the exception, but before swallowing, write a one-line diagnostic to a known-good fallback stream. The original record is still lost, but the failure itself is visible. The fallback is typically stderr (or a separate "internal logger" if your library has one).

write(record):
    if record.level < minLevel: return
    formatted = formatter.format(record)
    lock.acquire()
    try:
        sink.write(formatted)
    catch e:
        stderr.write("logger: sink write failed: " + e.message)
    finally:
        lock.release()

This is what production loggers actually do. Log4j has a StatusLogger that writes to stderr when an appender fails. Python's logging defaults to writing to sys.stderr when handlers raise. It balances "don't crash the caller" with "don't fail silently."

Low-Level Design

Logger Interface

Logger is the only class the application ever needs to know about. Everything else lives behind it.

Something has to be the public face of the library. When the application calls logger.info("..."), something has to capture the timestamp and thread name, build a LogRecord, and dispatch it to every configured destination. That's Logger.

It owns the list of destinations and exposes log() plus the convenience helpers (debug, info, warn, error, fatal) that callers actually use. It's the entry point and the only class the application ever touches.

interface Logger {
	/**
	* When a process starts, it calls 'start' with processId and startTime.
	*/
	void start(String processId, long startTime);

	/**
	* When the same process ends, it calls 'end' with processId and endTime.
	*/
	void end(String processId, long endTime);

	/**
	* Prints the logs of this system sorted by the start time of processes in the below format
	* {processId} started at {startTime} and ended at {endTime}
	*/
	void print();
}

class Logger:
    - destinations: List<Destination>   // immutable after construction

Why make List<Destination> immutable after construction?

The constructor takes the destinations once and stores an immutable copy. There's deliberately no addDestination, no setters, no builder. Config is fixed at startup, so the API doesn't expose a way to mutate it.

Iteration is safe under concurrent calls with no locking. A mutable list with addDestination() would force locking around iteration without buying anything the requirements asked for.

log(level, message) builds a LogRecord and dispatches.

info(msg) just calls log(INFO, msg). They're worth including because they match the API callers actually use. Calling log(LogLevel.INFO, "...") everywhere works, but it's noisier than info("..."), and a logger is infrastructure that tens of thousands of call sites will touch so the ergonomics matter.

log(level, message):
    // Build a LogRecord from those plus the caller's level and message.
    record = new LogRecord(
        // Capture the current timestamp
        timestamp  = now(),
        level      = level,
        message    = message,
        // Capture the current thread's name
        threadName = currentThread().name
    )
    // Iterate over destinations and call write(record) on each.
    for destination in destinations:
        destination.write(record)

now() and currentThread().name get called once at the top of log() rather than once per destination, so every destination sees the same record with the same timestamp and the same thread name.

Synchronize the entire log() method on Logger. Every call from every thread is serialized through one lock. A slow file write (disk full, contended I/O, unreachable network destination) now blocks every other call to log, including console writes that should have been instant. The right default for per-resource concurrency is one lock per resource. Here we're using one lock to protect five unrelated resources. This also blocks formatting, which doesn't need locking at all (records are immutable, formatters are stateless). Coarse locking is fine when the workload is sparse and the resources are uniform. Ours is neither.

LogRecord Class

LogRecord is the value object flowing through the system. LogRecord is the value object flowing through the system. Every log() call creates one, every destination consumes one, and the fields never change after construction. It's a dumb container by design: no behavior, just data.

Every call to log() generates a unit of data made up of a timestamp, a level, a message, and a thread name. These fields always travel together. Every destination receives them, every formatter serializes them, and they never change after creation.

That's the textbook case for a value object. Modeling them as one class instead of passing four parameters everywhere gives formatters a stable shape and lets you add fields later (a logger name, a request ID, a context map) without changing every method signature in the system.

class LogRecord:
    - timestamp: Instant
    - level: LogLevel
    - message: String
    - threadName: String

    + LogRecord(timestamp, level, message, threadName)
    + getters for all fields

A record represents what happened at one moment in one thread. None of those facts change after the call site. Making the fields immutable closes off a whole class of bugs. Any destination, any formatter, any future extension can read a record without worrying about racing another thread or accidentally mutating shared state.

LogLevel Enum

enum LogLevel:
    DEBUG
    INFO
    WARN
    ERROR
    FATAL
    // ordered: DEBUG < INFO < WARN < ERROR < FATAL

Formatter Interface

An interface for serializing a LogRecord to a string. Two implementations exist (plain text and JSON), and new formats become new implementations without touching anything else.

This is the Strategy pattern — pulling format behind its own interface lets a Destination compose whichever formatter it wants.

interface Formatter:
    + format(record: LogRecord) -> String

class PlainTextFormatter implements Formatter
class JsonFormatter implements Formatter

Formatters are pure functions. They take a record, return a string, end. That makes them safe to share across threads and across destinations. Two destinations can hold a reference to the same JsonFormatter instance without any synchronization, because there's nothing to synchronize.

Destination Class

It owns a minimum level threshold for filtering, a formatter for serializing, and the actual write mechanism for output. It also owns the per-destination lock for concurrent safety.

Naive Implementation

One concrete Destination class with a type field. The write() method branches on the type to decide what to do.

class Destination:
    - type: DestinationType            // CONSOLE | FILE
    - formatter: Formatter
    - minLevel: LogLevel
    - filePath: String                  // only used when type == FILE

    + write(record):
        if record.level < minLevel: return
        formatted = formatter.format(record)
        if type == CONSOLE:
            stdout.write(formatted)
        else if type == FILE:
            fileWriter(filePath).write(formatted)

This approach seems to break the moment you add a third destination. Every new target adds a branch in write(), and most of them add fields that only apply to that one target (filePath for files, socketAddress for remote, kafkaTopic for Kafka). You end up with a class where most fields are null for any given instance, and a write() method that's a switch statement masquerading as polymorphism.

The design problem is "behavior varies by type," and a switch statement is the answer that scales worst as types are added. It also violates Open/Closed, since every new destination type forces you to crack open Destination and edit existing logic.

Better Implementation

This is the textbook anti-pattern that interfaces and inheritance both exist to fix.

Inheritance with template method: Destination becomes an abstract base class that owns the filter-and-format logic. Subclasses implement the actual write step.

abstract class Destination:
    - formatter: Formatter
    - minLevel: LogLevel
    - lock: Lock

    + write(record):
        if record.level < minLevel: return
        formatted = formatter.format(record)
        lock.acquire()
        try:
            doWrite(formatted)
        finally:
            lock.release()

    # doWrite(formatted: String)        // abstract — subclass fills this in

class ConsoleDestination extends Destination:
    + doWrite(formatted): stdout.write(formatted)

class FileDestination extends Destination:
    - filePath: String
    + doWrite(formatted): fileWriter(filePath).write(formatted)

This is the template method pattern and it does the most important job. It puts the filter-and-format invariant in exactly one place. A new subclass author can't forget the level check or skip the formatter, because they don't write write(). They only write doWrite(). That's a real win over the type-branching version. The base class also gives you a natural home for the lock.

The problem with this approach is that inheritance is a heavy commitment for what's mostly a single axis of variation. ConsoleDestination and FileDestination don't actually share any data with their parent. They just inherit a method. That's a thin reason to use inheritance. The bigger pain shows up when you want to wrap a destination in something, say buffering or retry or a fan-out to two underlying targets. With an inheritance hierarchy, "wrap" means "subclass and override," which composes badly. You can't easily build a BufferedFileDestination without re-implementing the file-handling logic, and stacking two wrappers means three levels of inheritance for what should be one wrapping operation.

Suitable Implementation

Composition with Sink Interface: We're going with the composition variant. It keeps the filter-and-format invariant in one place (the same win as the inheritance approach), avoids a hierarchy that pays no real dividend, and gives the requirement-stated remote destination a clean place to land as a new Sink.

class Destination:
    - formatter: Formatter
    - minLevel: LogLevel
    - sink: Sink

    + Destination(formatter, minLevel, sink)
    + write(record: LogRecord)

interface Sink:
    + write(formatted: String)

class ConsoleSink implements Sink
class FileSink implements Sink:
    - filePath: String

Sink a small interface, one method and one responsibility, and it's where future extensions will plug in.

Destination.write() filters, then formats, then writes to the sink under a lock. One lock per Destination instance. The critical section covers sink.write(). Filter check and formatting happen outside the lock since the record is immutable and the formatter is a pure function.

class Destination:
    + write(record):
        if record.level < minLevel: return
        formatted = formatter.format(record)
        lock.acquire()
        try:
            sink.write(formatted)
        finally:
            lock.release()

This is the per-resource locking pattern. Each destination protects its own resource with its own lock, so a slow file write doesn't block console output, and a hung remote destination doesn't block file or console. The critical section is the smallest correct one, just the parts of write() that touch shared state (the sink). The parts that don't (filter, format) stay outside.

Follow-up Questions

Q. How would you make log() non-blocking?

The current design holds a per-destination lock around sink.write(). That's correct, but it means a slow file write or a flaky network destination blocks the calling thread for as long as the I/O takes. For a logger that fires from tens of thousands of call sites, that adds up to real latency in the application.

"I'd put a bounded blocking queue in front of each destination's sink. log() enqueues the record and returns immediately, and a dedicated worker thread per destination drains the queue and does the actual write. Concurrent producers, single consumer per resource, which means the consumer side doesn't even need a lock anymore."

class Destination:
    - formatter, minLevel, sink
    - queue: BlockingQueue<LogRecord>    // bounded
    - worker: Thread

    + Destination(formatter, minLevel, sink, capacity):
        this.queue  = new BlockingQueue(capacity)
        this.worker = startThread(drain)

    + write(record):
        if record.level < minLevel: return
        queue.put(record)                // blocks if full (or drop / throw)

    - drain():                            // runs on the worker thread
        while running:
            record    = queue.take()
            formatted = formatter.format(record)
            sink.write(formatted)         // single consumer, no lock needed

• Worker lifecycle: Each destination now owns a thread that runs for the life of the application. Shutdown is the tricky part — you have to signal the worker to stop, drain whatever's already in the queue, and wait for it to finish before the process exits. Skip that and you lose every record that was buffered when the JVM (or whatever) died.
• Overflow policy: A bounded queue forces a decision about what happens when it fills up. You've got four reasonable choices and each one is wrong for some workload. block the producer (which defeats the whole point of going async), drop the new record (which silently loses data right when something's going wrong), drop the oldest record (same problem, different end of the queue), or throw an exception (which turns logging back into something callers have to catch). Most production loggers default to drop-newest with a stderr diagnostic, but the right answer depends on whether you care more about not losing records or not blocking callers.
• Debuggability: The actual write now happens on a different thread than the call site. A stack trace at the moment of an I/O failure no longer points back to the code that emitted the record, which makes "why did this log line fail to write?" meaningfully harder to answer. You can mitigate by logging the record's call-site info into the diagnostic, but the gap is real.

Q. How would you support hierarchical named loggers?

Production loggers don't construct one global Logger and pass it around. They expose LoggerFactory.getLogger("com.app.service.payments"), and the returned logger inherits configuration from its parent in the dotted-name tree. The team that owns com.app.service can set its threshold once and have everything underneath pick it up unless overridden.

The factory is a deliberate global. The whole point of the registry is that two callers anywhere in the codebase asking for getLogger("com.app.service") get back the same instance. That's the rare case where shared application state is the requirement, not an accident.
