System Design (Razorpay): Payment System

June 15, 2026

Design a payment processing system like Razorpay that allows merchants (businesses) to accept payment from their customers.

razorpay

Functional Requirements

  1. All transactions should be persisted. Financial auditing standards require us to maintain immutable records of every payment attempt, success, and failure.

Non-Functional Requirements

  1. Secure payment workflow. Proper merchant authentication.

  2. The system shoulbe be able to handle 10,000 transactions per second (TPS) at peak load.

Sequence Flow

  1. Customer reaches the checkout page and input payment details.

  2. The merchant makes an API call to our system by sending a POST request to /payment-intents with details like amount, currency, and description.

  3. Once authenticated, the request is routed to the PaymentIntent Service.

  4. The PaymentIntent Service creates a new PaymentIntent record with an initial status of "created" and stores it in the Database.

  5. The system generates a unique identifier for this PaymentIntent and returns it to the merchant in the API response.

Load Estimation

Storage Capacity Estimation

Bandwidth Estimation

Design Rationale

Q. What happens if a payment fails?

No transaction data should ever be lost, even in case of failures. It would both be a financial and legal disaster.

Consider this scenario that happens daily in production systems:

  1. We send a $200 charge request to the customer's bank
  2. The bank approves and debits the customer's account
  3. The response packet gets delayed or lost in network congestion
  4. Our 30-second timeout triggers, we mark the payment as "failed"
  5. The merchant displays "Payment failed, please try again"
  6. The customer retries, creating a second $200 charge
  7. The customer now has $400 in charges for a $200 purchase

Q. Why do we need a separate audit table?

We need to track not just what the current state is, but the entire sequence of events that led to that state. When a customer disputes a charge six months later, we must be able to prove exactly what happened: when the payment was initiated, what amount was authorized, when it was captured, and whether any refunds were processed. A single missing record could mean inability to defend against chargebacks, failed compliance audits, or worse—being unable to determine the true state of customer accounts.

High-Level Design

API Design

Data Model Design

Extra

Payment processing is inherently asynchronous.

Payment networks - Visa, Mastercard, American Express - actually authorize and process the financial transactions. Payment networks operate on private, highly secure networks that are completely separate from the public internet.

What are replay attacks?

What is API key management with request signing? What is secret key based authentication?

How iframes help me ensuring the merchant's server is not bothered with customer card details?

Webhooks - server to server communication

Websockets, SSE - server to client communication
